Water source heat pump inverter 23kw r32

EEHDC/23-R32

New product

Geothermal heat pump Dc inverter 23kW reversible
  • High capacity 23kW
  • R32 preloaded gas
  • DC inverter technology
  • Compact
  • One-piece design (easy installation
  • COPELAND© compressor
  • Efficient and economical
  • Reversible hot/cold

More details

4 250,00 €

Price including VAT + Shipping included

Add to wishlist

Alert me when price drops

More info

Technical data:

Capacity (hot water): 23kW* max.
Energy absorbed: 3.62kW
BTU/h: 78 430
COP: 6.27 max.**

Capacity (cold water): 21.5kW max.
Energy absorbed: 3.57kW
BTU/h: 73 315
EER: 6.02 max.

Power supply: 380-440V / 3ph / 50Hz

Consumption: 9.52A (hot), 9.39A (cold)

Water flow (geo. source): 6200L/h
Water flow (circuit): 3600L/h

Hydraulic connections: DN32

Max hot water outlet temperature: 60°C
Cold water production: 7-12°C

Plate heat exchanger

Compressor: 1x Twin rotary
Refrigerant gas: R32

Sound emission in operation: <32dB(A)

Net dimensions: 79 x 54 x 112 cm
Net weight: 120kg

Total warranty 36 months



*Testing conditions:

Inlet water source temperature: 10°C
Outgoing hot water temperature: 35°C

**COP 4.86 @B0W35
