> >>On-Grid Solar Inverter 10kW (VDE126)
Inverter solar network 6kW (Controller) View larger

On-Grid Solar Inverter 10kW (VDE126)

FPS/10KW-B

New product

On grid Inverter 10kW

  • Compact size and high power
  • High speed MPPT for real time power tracking and improved energy harvesting
  • Transformerless design to get maximum efficiency: 98.2%
  • Grid connection according to international standards
  • True sine wave output
  • RS-232/485 serial communication
  • Multi-language display.

More details

2 090,00 €

Price including VAT + Shipping included

Add to wishlist

Alert me when price drops

More info

Specifications:


Input Data: DC

Max DC Power: 11200W
Max DC Voltage: 900Vdc
MPPT Operating range: 200-800Vdc
Parallel inputs: 4
MPPT Trackers: 2
Max. input current (total): 36A (18A per tracker)

Output Data: AC

Nominal output power: 10000W
Max. output power: 10000W
Nominal output current: 14.5A per phase
Max. output current: 16A per phase
Nominal AC voltage: 400Vac
AC Voltage range: 330-480Vac
Nominal AC grid frequency: 50Hz
AC grid frequency range: 50Hz (+/-5)
Power Factor: >0.9(leading) 0.9(lagging)
Harmonic distortion (THD): <3% (at nominal output power)

Efficiency:

Max. efficiency: 98.2%
Euro efficiency: 97.6%
MPPT efficiency: 99.6%

General data:

Dimensions (W*D*H): 345*162*573mm
Net weight: 26Kg
Operating temperature range: -25°C to +60°C
Operating noise: <25 dB(A)
Power consumption at night: 0W
Electrical isolation: Transformer-less
Cooling system: Passive
IP Code: IP65
Communication: RS-232 and RS-485

Certification:

VDE 126-1-1
EN-50178
EN-61000
AS4777
DK5940
IEC 62109-1 / 62109-2
