> >>Complete 3kW photovoltaic solar kit for grid injection
Sale! Complete solar kit 3kW View larger

Complete 3kW photovoltaic solar kit for grid injection

K3kW/330

New product

Complete 3kW solar kit consisting of:

  • 10x 330W high performance PV
    High performance monocrystalline cells (grade A).
    (CE + TUV certified) 10-year warranty
  • 1 VDE126 compliant solar grid inverter with 5-year warranty
  • WiFi function
  • Adjustable angle mounting brackets tested against wind (55m / s) snow (1.5kn / m²)
  • Cables 4mm² (100m)
  • Total power: 3300Wp

More details

5 250,00 €

Price including VAT + Shipping included

Add to wishlist

Alert me when price drops

More info

Technical data of a solar panel *:

Module type: Monocrystalline
 Peak power: 33 0 Watts

Optimal Operating Intensity (Imp): 9.93A
Open Circuit Voltage (Voc): 46.34V
Optimal operating voltage (Vmp): 33.2V

Net dimensions: 195cm X 99.5cm X 3.5cm
Weight: 25kg / piece
Junction box supplied
Frame: Universal anodized aluminum frame.
Lifespan: 25 years minimum.
Guarantee: 10 years

Efficiency: 21%
Certificates ： CE, TUV

Technical data of the inverter:

Power: 3kW

MPPT: 180-450V

Max voltage input: 500V
Output voltage: 190 to 270V

Number of MPPs: 1
DC input number: 1

Communication interface: RS845

Dimensions: 400 x 305 x 150mm

Guarantee: 5 years


Package Information:

Total volume: 1.2 m3
Total weight: 360kg
